PLC Control Colored Cold Steel Terrazzo Roof Tile | RFQ Sourcing Details
Bending And Forming · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Product specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Bending And Forming. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
ROLL FORMING MACHINE FOR YX TILE ROOF PROFILE If customization : Yes Type : Roll former for tile roof profile Types : YX tile roof Overall Dimensions: 11400mm×1960mm×1580mm (estimated only) Total G.W.: 12500KG (estimated only) Price: USD39000.00 (Depends on different specification) Payment terms : 30%T/T deposit, 70%T/T or L/C balance Shipping Container : 1*40GP (reference only) Delivery time : 90 days Brand : LM Option for Certification: CE, SONCAP etc., (as per the customers ' requirements) YX ROLL FORMING MACHINE FOR TILE ROOF PROFIL The Chart of Process Flow: Technical Parameters : The main technical parameters are for your inference only.
Only if you provide the profile required or the real objects of sectional materials, and we will offer the accurate parameters. (1) 5.
Tons manual un-coiler Description There are different choices, please turn to the catalogue of un-coiler (2) Entry bench & Manual Pre-shearing device Function Smart cut control, to cut off the end of the final piece of sheet only Shearing Thickness Up to Max.
0.8mm (if thickness > 0.8mm, then hydraulic pre-shearing device or electric pre-shearing device instead ) (3) The general machine parameter Suitable roll forming material Color steel sheet or Aluminum Thickness 0.4mm-0.6mm Feeding width 1219mm Frame design Wall-plate-frame-design /New-stand-frame-design Roll stages 18 stages Material of forming roller 45# steel, CNC lathes, Hard Chrome Coated Shafts Diameter Φ75 mm Main motor power 7.5KW with reducer Max.
Line speed of roll former Approx.
4m/min (stair length 350mm, production length 6m) Hydraulic Stair-Drawing & Cutting Device There is one hydraulic press to make the stair according to requirement and hydraulic post cut for cut off Hydraulic group power 11KW Material of cutting blade Cr12, heat treatment Electric Standard 380V /50.
Hz/3PH or as the customer's requirements Machine Dimensions 9430mm×1960mm×1650mm Major Color of Machine Painted RAL 5015 (Blue) or as per customer's requirements (4) PLC Control system PLC Siemens brand (ABB brand is available if required) Touch Screen Siemens brand (ABB brand is available if required) Inverter Schneider brand (ABB brand is available if required) Encoder Omron brand (5) Product rack Description un-powered, 3 units (6) Options for tile roof : A.Hydraulic pre-shearing device B.Improvement for driving system for T
PLC | Applications and Buyer Notes
PLC is organized as a sourcing-ready Bending And Forming reference. The page combines visible product or company data with structured procurement cues so buyers can compare application fit, specifications, quantity, quality requirements and lead-time questions
Applications
- Initial shortlist building for related product or supplier options.
- Specification and application fit review before bulk purchasing.
- Category, keyword and detail-page comparison before sending an RFQ.
Key specifications
- Category
- Bending and FormingBased on visible page data; confirm exact value in the RFQ.
- Unit
- setBased on visible page data; confirm exact value in the RFQ.
- power
- 11KWBased on visible page data; confirm exact value in the RFQ.
- Diameter
- Φ75 mm Main motorBased on visible page data; confirm exact value in the RFQ.
- Standard
- 380V /50Hz/3PH or as the customer's requirements Machine Dimensions 9430mm×1960mBased on visible page data; confirm exact value in the RFQ.
- material
- Color steel sheet or Aluminum Thickness 0.4mm-0.6mm Feeding width 1219mm Frame dBased on visible page data; confirm exact value in the RFQ.
- customization
- YesBased on visible page data; confirm exact value in the RFQ.
Buyer tips
- State quantity range and split-delivery needs before price comparison.
- Add certification, material or inspection standards when they affect acceptance.
- For time-sensitive projects, include target arrival date and destination.
- For special applications, describe operating condition, installation environment and duty cycle.
FAQ
What should buyers confirm first?
Confirm application, specification, quantity, destination and lead-time requirements before comparing offers.
Can buyers inquire when specs are incomplete?
Yes. Add model, material, size, use case and inspection needs in the RFQ to make replies comparable.
How should this listing be evaluated?
Check title, category, specifications and related keywords against the actual sourcing requirement.
